Tanglenomicon Core Libraries

The Tanglenomicon core libraries repository consists of a collection of libraries for computation and generation of knot/tangle data. Each library should be considered its own project with its own life-cycle however libraries are loosely coupled by a common CMake interface.

The libraries found here are primarily C, the C modules are expected to be C++ linkable. There's no target OS, but Ubuntu Linux with Nix is the CI OS. Each library will adhere to a common design that allows them flexibility and platform and language agnosticism. The design allows a library, maybe "calculate Jones polynomial", to be runnable in a Jupyter notebook during undergraduate knot theory class, or wrapped in MATLAB interfaces for scientific computing, or on a university cluster for high-performance use cases.

We're targeting a "write once deploy anywhere" design.

Planning

Tasks

Tasks will be decomposed per library. Issues/bugs will be tracked per report, combining where it makes sense.

Version Control

Version control will be git based with research Git as the source of truth. Work items will have a branch per work item. Merging a work item will be managed by merge requests.

Release Schedule

A release will be created at the completion of each feature life cycle.

Release Tagging

The project adopts semantic versioning for version labels.

vMAJOR.MINOR.PATCH

Since a release is created for every feature implemented the project version may look odd v0.20.0 this is OKAY.

It is required that every feature module in the project maintain its own semantic

versioning. It is suggested to check for compatibility of used libraries at compile time.

Software Life Cycle

We're taking a V-model approach with design, implementation, integration, and testing phases.

graph TD
    A[Requirements] --> B[Design]
    B --> D[Unit Design]
    D --> E[Implementation]

    E --> F[Unit Testing]
    F --> G[Integration Testing]
    G --> I[Acceptance Testing]

    I -->|Validation| B
    G -->|Validation| B
    F -->|Validation| D

This methodology allows us to have high traceability through the development process. Allowing us to justify every decision made in the process.

Project Structure

Project structure will follow a fairly "normal" project structure as follows:

📦tanglenomicon_core
 ┣ 📂.github
 ┃ ┗ 📂workflows
 ┃   ┗ 📜\<github workflows\>
 ┣ 📂data
 ┃ ┗ 📜\<Static data files\>
 ┣ 📂docs
 ┃ ┣ 📜\<Sphinx files\>
 ┃ ┗ 📜Doxyfile
 ┣ 📂libraries \< external libraries\>
 ┃ ┗ 📜\<C/C++ libraries data files\>
 ┣ 📂misc
 ┃ ┗ 📜\< Single use tooling\>
 ┣ 📂source
 ┃ ┗  📂\<Module\>
 ┃    ┣ 📂source
 ┃    ┃ ┗ 📜\<Module Source Files\>
 ┃    ┣ 📂test
 ┃    ┃ ┗ 📜\<Module unit test Files\>
 ┃    ┣ 📜use-case.md
 ┃    ┗ 📜unit-description.md
 ┣ 📂tests
 ┃ ┣ 📂results
 ┃ ┃ ┗ 📜.gitkeep
 ┃ ┗ 📂integration_tests
 ┃   ┗ 📂 \<integration Test Suites\>
 ┣ 📜.clang-format
 ┣ 📜.clang-tidy
 ┣ 📜.gitignore
 ┣ 📜CMakeLists.txt
 ┣ 📜CMakeSettings.json
 ┣ 📜README.md
 ┗ 📜requirements.txt

Define a Unit: A Unit in This Project Shall Be a Monorepo Member of the Source Directory

Quality

This repository is a collection of libraries for The Tanglenomicon project. The primary quality goal of libraries is to never fail in an undetectable way.

Unit Testing

Every unit is expected to have a unit test suite. Unit test suites are expected to flex every public interface of that unit. Code coverage is optional but encouraged.

Integration Testing

Integration testing is not expected.

Requirements

Since this repository contains a collection of libraries, this section will describe the high-level design for types of libraries/common use cases.

Functional Requirements

flowchart LR
    Runner
    subgraph "Runnables"
        Generator
        Computation
    end
    subgraph "Data Wranglers"
        Notation
        Storage
        Mutator
    end
    Runner -->|Runs| Generator
    Runner -->|Runs| Computation
    Generator -->|Uses| Mutator
    Computation -->|Uses| Mutator
    Generator -->|Uses| Notation
    Computation -->|Uses| Notation
    Generator -->|Uses| Storage
    Computation -->|Uses| Storage

These common use cases along with their associated unit descriptions are found below:

Computation

Generator

Mutator

Notation

Storage

Non-Functional Requirements

Not applicable.

Technologies

Languages/Frameworks

The runnable and data wrangler libraries will be written in C/C++ using clang for compiling and cmake as a build system. The runners are written with various tooling including C/C++, Python, and JavaScript.

Unit testing of runnable and data wrangler libraries will use the Unity and Cmock libraries for unity testing. Test indexing is handled by CTest.

Code Style Guide

The C/C++ code in this repository shall be formatted by the bundled uncrustify configuration.

Tools

git
mermaid.js
Unity
clang
cmake
CTest
Doxygen
Cmock
Python
sphinx
Pytest
prek
uncrustify
mdformat

Design and Documentation

C/C++ code is documented with Doxygen, the Doxygen comments shall be parsed and output as XML. General documentation shall be recorded as markdown files in each module's directory. Documentation shall be aggregated using the Sphinx framework. Sphinx shall then use Breathe to parse Doxygen XML into the general documentation.

Colors

Diagrams included in documentation for features (use case and unit descriptions) is expected to use the COLORS color palette.

/* Colors */
.navy {
    color: #001f3f;
}
.blue {
    color: #0074d9;
}
.aqua {
    color: #7fdbff;
}
.teal {
    color: #39cccc;
}
.olive {
    color: #3d9970;
}
.green {
    color: #2ecc40;
}
.lime {
    color: #01ff70;
}
.yellow {
    color: #ffdc00;
}
.orange {
    color: #ff851b;
}
.red {
    color: #ff4136;
}
.fuchsia {
    color: #f012be;
}
.purple {
    color: #b10dc9;
}
.maroon {
    color: #85144b;
}
.white {
    color: #ffffff;
}
.silver {
    color: #dddddd;
}
.gray {
    color: #aaaaaa;
}
.black {
    color: #111111;
}
